Additional information

Country of Origin

United States

PID

863836

Product depth (mm)

160

Product height (mm)

39

Product weight (g)

520

Product width (mm)

160

Ethernet (RJ-45) ports quantity

1

MIMO

Yes

Product Family

Aruba Networking

Manufacturer address

Keilaniementie 1, 02150 ESPOO

Manufacturer's email address

support.hpe.com

Manufacturer name

Hewlett-Packard Oy

The Aruba 610 series campus access points are designed to take advantage of the 6 GHz frequency band, achieving a combined maximum data transfer speed of up to 3.6 Gbps. This means you can enjoy greater capacity and faster speeds indoors. By adding support for the 6 GHz frequency range, capacity increases by up to 1200 MHz, and it introduces 80/160 MHz channels to meet the growing demands driven by bandwidth-intensive video, an increase in the number of client and IoT devices, and the expansion of cloud service usage.

Compact and cost-effective, the Aruba 610 series features two software-programmable radios that can be tuned to any two of the three Wi-Fi 6E bands: 2.4 GHz, 5 GHz, and 6 GHz. Full tri-band coverage is available when deploying multiple access points. Thanks to built-in GPS receivers and fine-grained timing, the Aruba 610 series campus access points can automatically locate themselves and serve as reference points for precise indoor location measurements.

New Features:

  • Unlock the 6 GHz frequency band, providing up to 1200 MHz of additional capacity and peak combined data speeds of up to 3.6 Gbps.
  • Support for up to seven 160 MHz channels in the 6 GHz frequency band, catering to low-latency and bandwidth-intensive applications like high-definition video and augmented/virtual reality applications.
  • Software-programmable dual-radio modes offer cost-effective coverage across two of the three Wi-Fi 6E frequency bands: 2.4 GHz, 5 GHz, and 6 GHz, with full tri-band coverage in multi-AP deployments.
  • Low power consumption enables unlimited operation from an 802.3af (class 3) PoE source.
  • Built-in GPS receivers and precise timing allow for automatic AP location and serve as reference points for accurate indoor positioning measurements.

Request a quote from our business sales team!

Technical Specifications:

  • Ports: 2 x RJ-45 10/100/1000 Mbps
  • PoE Power Input: 48 Vdc (nominal) 802.3af/at/bt PoE (class 3 or higher)
  • 802.3az Energy Efficient Ethernet (EEE)
  • Radio: two radios (a/b/g/n/ac/ax), 2.4 GHz, 5 GHz, and 6 GHz 2 x 2 MIMO, up to 3.6 Gbps
  • Bluetooth Low Energy (BLE5.0)
  • Zigbee (802.15.4) radio
  • Antenna: two internal omnidirectional and downward-facing dual-band antennas with gains: 4.6 dBi / 2.4 GHz, 7.0 dBi / 5 GHz, and 6.3 dBi / 6 GHz
  • 802.3 af/at/bt Power over Ethernet support
  • Max. 256 devices per radio, max. 16 BSSIDs per radio
  • Power Supply: 12 Vdc from power connector or 48 Vdc PoE-PD
  • Power Consumption: 20.9 W max PoE, 18.2 W max with power supply.
  • Operating Temperature: 0° C – +40° C
  • Dimensions: 20.1 x 18.3 x 5.1 cm
  • Weight: 720 g
  • Includes mounting clips for T-bar ceiling (15 mm and 24 mm)
  • Warranty: limited lifetime warranty*

*Valid for the device’s first owner for the duration of the model’s lifecycle (+5 years from discontinuation). The first 30 days include Same Day Advanced Shipment, after which a replacement unit will be delivered within 10 days of the manufacturer receiving the defective product. Technical support for the first 90 days.

Toote pildid on illustratiivsed ja näitlikud. Originaaltoote omadused võivad nende tegelikust väljanägemisest erineda, seega palun tutvuge tootekirjelduses toodud tootespetsifikatsioonidega.
LAOS OLEMAS

HPE Aruba AP-615 (RW) Dual-Radio Tri-Band 2×2:2 802.11ax Wi-Fi 6E Access Point

706.79
sis. KM 24%
  • Three frequency bands (2.4 / 5 / 6 GHz)
  • 802.3 af/at/bt PoE
  • Up to 3.6 Gbps
  • Requires a controller
Eeldatav tarneaeg: 4-7 päeva
Maksa hiljem või osana
Tootekood: R7J49A
EAN kood: 0190017493114, 2220008638366

The Aruba 610 series campus access points are designed to take advantage of the 6 GHz frequency band, achieving a combined maximum data transfer speed of up to 3.6 Gbps. This means you can enjoy greater capacity and faster speeds indoors. By adding support for the 6 GHz frequency range, capacity increases by up to 1200 MHz, and it introduces 80/160 MHz channels to meet the growing demands driven by bandwidth-intensive video, an increase in the number of client and IoT devices, and the expansion of cloud service usage.

Compact and cost-effective, the Aruba 610 series features two software-programmable radios that can be tuned to any two of the three Wi-Fi 6E bands: 2.4 GHz, 5 GHz, and 6 GHz. Full tri-band coverage is available when deploying multiple access points. Thanks to built-in GPS receivers and fine-grained timing, the Aruba 610 series campus access points can automatically locate themselves and serve as reference points for precise indoor location measurements.

New Features:

  • Unlock the 6 GHz frequency band, providing up to 1200 MHz of additional capacity and peak combined data speeds of up to 3.6 Gbps.
  • Support for up to seven 160 MHz channels in the 6 GHz frequency band, catering to low-latency and bandwidth-intensive applications like high-definition video and augmented/virtual reality applications.
  • Software-programmable dual-radio modes offer cost-effective coverage across two of the three Wi-Fi 6E frequency bands: 2.4 GHz, 5 GHz, and 6 GHz, with full tri-band coverage in multi-AP deployments.
  • Low power consumption enables unlimited operation from an 802.3af (class 3) PoE source.
  • Built-in GPS receivers and precise timing allow for automatic AP location and serve as reference points for accurate indoor positioning measurements.

Request a quote from our business sales team!

Technical Specifications:

  • Ports: 2 x RJ-45 10/100/1000 Mbps
  • PoE Power Input: 48 Vdc (nominal) 802.3af/at/bt PoE (class 3 or higher)
  • 802.3az Energy Efficient Ethernet (EEE)
  • Radio: two radios (a/b/g/n/ac/ax), 2.4 GHz, 5 GHz, and 6 GHz 2 x 2 MIMO, up to 3.6 Gbps
  • Bluetooth Low Energy (BLE5.0)
  • Zigbee (802.15.4) radio
  • Antenna: two internal omnidirectional and downward-facing dual-band antennas with gains: 4.6 dBi / 2.4 GHz, 7.0 dBi / 5 GHz, and 6.3 dBi / 6 GHz
  • 802.3 af/at/bt Power over Ethernet support
  • Max. 256 devices per radio, max. 16 BSSIDs per radio
  • Power Supply: 12 Vdc from power connector or 48 Vdc PoE-PD
  • Power Consumption: 20.9 W max PoE, 18.2 W max with power supply.
  • Operating Temperature: 0° C - +40° C
  • Dimensions: 20.1 x 18.3 x 5.1 cm
  • Weight: 720 g
  • Includes mounting clips for T-bar ceiling (15 mm and 24 mm)
  • Warranty: limited lifetime warranty*

*Valid for the device's first owner for the duration of the model's lifecycle (+5 years from discontinuation). The first 30 days include Same Day Advanced Shipment, after which a replacement unit will be delivered within 10 days of the manufacturer receiving the defective product. Technical support for the first 90 days.
