The XT series is designed to offer more cooling capacity and interior space for the latest motherboard versions. Thanks to the case’s length and width, it easily accommodates even the largest graphics cards, and there is also enough room for cable management. Cooling is optimized with up to 10 x 120 mm fan slots, support for 140 mm fans, and a separate cooler at the top of the case.

• Support for the largest graphics cards
• Separate 360 mm radiator space on the top
• Up to 10x 120 mm fan slots
• Up to 6 x 140 mm fan slots
• Support for motherboards with the latest rear connectors such as MSI Project Zero and ASUS BTF motherboards
• USB-C 3.2 Gen 2
• Triple SSD Bracket

Features:

• Motherboard support: ATX, Micro-ATX, Mini-ITX, E-ATX (up to 280 mm without GPU support bracket)
• Rear motherboard support: Supports MSI Project Zero and ASUS BTF motherboards
• Size: Mid Tower
• Material: Steel, tempered glass, ABS plastic
• Color: Satin black
• 5.25″ bays: 0 pcs
• 2.5″ bays: 5 pcs
• 3.5″ bays: 2 pcs
• Connections: Power switch, reset switch, Power LED, HDD LED, HD audio, USB 3.0, USB 3.2 GEN 2 Type-E
• Front panel connections: 1x USB-C 3.2 GEN, 2 + 1x USB 3.0, microphone/headphone jack, reset button, power button

  Vertical GPU support: Yes, with optional bracket (PH-VGPUKT4.0_03R)

• Expansion slots: 7
• Maximum PSU depth: 270 mm
• Maximum CPU cooler height: 184 mm
• Maximum graphics card length: 415 mm
• Maximum graphics card width: 184 mm
• Top 360 radiator space: 415 x 138 x 60 mm
• Rear 120 radiator space: 120 x 170 mm
• Dimensions: 450 x 230 x 500 mm
• Weight: 8.17 kg
• Delivery includes 1x XT Pro Ultra case, 4x M25-140 D-RGB fans, 1x DRGB Mainboard Adapter, 1x USB Type-C 3.2 Gen 2 + 1x USB 3.0, brackets: 2x HDD / 1x HDD + 2x SSD 1x Triple SSD, accessory pack with screws

Fan slots:

• Top: 3 x 120 mm / 2 x 140 mm
• Rear: 1 x 120 mm / 1 x 140 mm
• Front: 3 x 120 mm / 3 x 140 mm
• Middle plate: 3 x 120 mm

Radiator support:

• Top: up to 360 mm
• Rear: 120 mm
• Front: up to 240 mm
