Join the ranks of countless legendary synthesizers with the Behringer UB-Xa synthesizer! The UB-Xa is more than just a faithful reproduction of the classic polyphonic analog synth: modern features like keyboard velocity sensing and aftertouch, 512 memory slots, and full MIDI support make this instrument extremely versatile, fitting perfectly into many genres and uses with its sound.

Behringer dove deep to deliver the iconic OB-Xa’s 80s grit: its VCO and VCF circuits, heavily based on the original 3340 and 3320 chips, 16 voices, and the ability to split the keyboard into two different sounds make it a highly expressive synth for creating massive synth riffs. The UB-Xa stands on the shoulders of giants, its predecessor having been used by artists like Rush, The Police, Prince, and Van Halen, not to mention the iconic Terminator theme music, and now offers the opportunity to tap into the sound world that has inspired numerous artists.

Features:

• Analog polyphonic synthesizer including the original factory presets of its inspiration
• 16-voice polyphony, 2 VCOs per voice, oscillator sync
• Oscillators with sawtooth, triangle, or square wave with adjustable pulse width
• VCOs and VCF based on recreations of the original 3340 and 3320 semiconductor designs
• Vintage mode: selectable 8 synthesizer “signatures,” e.g., OB-Xa, OB-8
• Multi-timbral: split or layer 2 different sounds
• Selectable dual-slope 12 / 24 dB analog low-pass filter per voice, adjustable resonance
• 61 semi-weighted, full-size keys, polyphonic aftertouch, velocity sensitive
• Versatile 8-channel modulation matrix
• Dual-layer arpeggiator and sequencer with real-time transposition
• 2 independent LFOs with 7 waveforms for modulating pulse width, oscillator pitch, or filter cutoff
• 2 ADSR generators per voice for controlling VCF and VCA
• Stereo VCA per voice – provides control over voice/layer panning
• 26 rotary controllers for direct and real-time parameter adjustment
• High-quality LCD display with encoder for fast navigation
• Assignable preset recall switches
• Spring mechanism implemented pitch and modulation wheels for total hands-on control
• 512 user memory slots with “compare and match” function
• Fully servo-balanced outputs for the highest possible signal quality
• CV/pedal inputs for expression pedals and footswitches
• MIDI and MPE support
